LIGHTPLATE 12030
3000K/CRI80 on/off incl Wieland con.
CIE Flux Codes | 47 79 95 100 100 |
Colour Deviation (SDCM) | 3 sdcm |
CRI | 80 |
Cut Out Dimensions | 1192x295 |
Dimensions | 1195x295x45 |
Energy Efficiency Class | A++ |
Forward Voltage | 42V |
Frequency | 50-60Hz |
IK | 05 |
Kleur | Wit |
Led type | SMD |
Lumen Maintenance | L80B10 bij 50.000 |
Lumen/W | 130lm/W |
Luminous flux of luminaire | 5460lm |
Material Housing | Aluminium |
Material Lens/Reflector/Diffusor | PMMA |
Max. connected Load | 42W |
Mounting Type | Inbouw |
PF | 0,9 |
Protection Class | I |
UGR | <24 |
Voltage | 220-240V |
Weight | 500g |
Reference : 000024937
Product Description
Paneel geschikt voor systeemplafonds. Voorzien van hoogwaardige reflectiefolie en achterliggende LED-modules voor een optimale efficiëntie. Gelijkmatige lichtuitstraling en hoogefficiënte optiek voor een brede lichtverdeling. Het technische ontwerp van dit armatuur zorgt voor een interessante UGR. Afmetingen: 597x597x49. Zowel verkrijgbaar in 6060 (Afmetingen: 597x597x49) - als 12030 (Afmetingen: 1195x295x45) -uitvoering. Uitzaagmaat bij uitsnijding in gyprocplafonds: 6060: 588x588 en 12030: 1192x295. Beschikbaar in 3000K en 4000K. Optioneel: opbouw, pendel, inbouw in gyproc mits extra accessoires, inbouw modulaire plafondsystemen mist extra accessoires. Standaard aan/uit. Optioneel dimbaar: dali, dali push, triac, 1/10V. Noodmodule mogelijk in combinatie met aan/uit of dali. Optioneel wielandstekker.
