LINIA 3535 300
9010 3000K/CRI80 1-10V
| Beamangle | 120 |
| CIE Flux Codes | 49 80 95 99 100 |
| Colour Deviation (SDCM) | 3 sdcm |
| Colour Temperature | 3000K |
| Max. connected Load | 100W |
| Connected Voltage | 220-240V |
| CRI | 85 |
| Dim | 1-10V |
| Dimensions | 3004x35x35 |
| ENEC | Ja |
| Energy Efficiency Class | D |
| Forward Voltage | 105V |
| Frequency | 50-60Hz |
| Glow Wire Test | 650°C |
| IK | 07 |
| Input current | 650mA |
| IP | IP44 |
| Color | RAL9010 |
| Led type | SMD |
| Lumen Maintenance | L80B10 bij 50.000 |
| Lumen/W | 100lm/W |
| Luminous flux of luminaire | 10000lm |
| Material Housing | Aluminium |
| Material Lens/Reflector/Diffusor | PMMA |
| Mounting Type | Ceiling |
| PF | 0,98 |
| Protection Class | I |
| Standby Power | 0,3W |
| UGR | <25 |
| Weight | 0,75kg/m |
Reference : 000005381
Product Description
Rectangular linear lighting, famous for its sophisticated appearance. It can be used in offices to dining rooms, where general lighting with an architectural touch dominates. Available in RAL9005, RAL9010, RAL9016, aluminium or a RAL colour of your choice. The product range of the LINIA3535 is very wide, allowing you to provide different rooms with one type of lighting. Choose surface mounting, recessed, pendant or wall mounting for the desired effect. There are also options for light emission such as spot lighting (Oculi, Argus, Wink) and strategic blind covers. Possible LED drivers are dali, dali push or on/off. Optional: emergency unit and dali sensor. Driver internal. Dimensions: 3004x35x35
